MagnaFlow Exhaust Products 51213 - OEM Grade Manifold Catalytic Converter
Couldn't load pickup availability
Magnaflow OEM Grade Manifold Catalytic Converter
Keep the check engine light off with MagnaFlow OEM Grade Federal/EPA Compliant Direct-Fit Manifold Catalytic Converter 51213. With features including free-flowing mandrel-bent tubing and highly corrosion resistant stainless steel construction, easily install this converter yourself using the proper tools, no cutting or welding required. MagnaFlow's state-of-the-art metrology department uses the latest 3D scanning systems during research and development, so you can be confident that your new part will fit and function like the original equipment. By replicating the OE design, the single laser fusion weld greatly reduces the possibility of a leak, and our compact, low-mass design also allows for greater thermal efficiency. This Direct-Fit Manifold Catalytic Converter is designed to fit the 2002-2004 Volkswagen Passat 4.0L. MagnaFlow 51213 includes (3) Flat Washers, (3) Nuts, (1) Flange Gasket and interchanges with OE parts 07D 253 020 EX, 07D 253 020 HX, 07D 253 020 JX. This replacement part is designed to meet or exceed Federal emissions requirements set forth by the EPA, complying with legal standards for OBDII Federally registered vehicles with California or Federal/EPA Emission systems.
Features
- Your trusted source for EPA-compliant catalytic converters, providing assurance of genuine compliance while delivering quality that will last
- High strength 16 gauge 409 stainless steel tubing for exceptional corrosion resistance and maximum service life
- Durable 308 stainless steel MIG welds
- Expertly crafted to replicate OEM-like flow dynamics, maintaining factory performance and fuel efficiency
- Simplifies installation with essential gaskets and hardware being included in the box
- Mandrel bent tubing retains OEM-like design and geometry, ensuring smooth exhaust flow for peak fuel economy and engine operation
Specifications
| Converter Body Length | 8.5 IN |
| Clamps Included | No |
| California Air Resources Board (CARB) Certified | No |
| Converter Tube Material | Stainless Steel |
| Converter Body Material | Stainless Steel |
| CARB Executive Order Number | Not Applicable |
| Body Type | Spun |
| Grade Type | Regular |
| Heat Shield Attached | No |
| Inlet Gasket Included | No |
| Inlet Mounting Hardware Included | No |
| Sensor Port Count | 2 |
| Overall Length | 24.75 IN |
| Substrate Material | Ceramic |
| New York Certified | No |
| Prop 65 Y/N | No |
| Series | OEM Grade |
| Type | One-Piece |
| Material | Stainless Steel |
| Outlet Gasket Included | Yes |
| Outlet Mounting Hardware Included | Yes |
| Inlet Type | Flange |
| Outlet Type | Flange |
| Finish | Uncoated |
Note: Not legal for sale or installation in California, Colorado or New York.
