AutoMeter 1211 - GAUGE, QUAD, 5", 240OE-33OF, ELEC, DESIGNER BLACK II
Product Availability Request
Fill the form and our team will contact you.
5" QUAD GAUGE, 100 PSI/100-250 F/8-18V/240-33 Ohm, DESIGNER BLACK II
Sometimes space is limited. The AutoMeter Quad Gauge provides a solution to limited dashboard space while providing a clean look. Individual AutoMeter air core meter movements for each function provide the accuracy and durability required by even the most demanding applications. Includes a single wire 1/8” NPT temperature sender and a 1/8” NPT oil pressure sender. The voltmeter reads from 8-18v on negative ground electrical systems and fuel level resistance range is 240 ohms empty to 33 ohms full (compatible with AutoMeter’s 3262 fuel level sender).
Features
- Highly polished chrome bezel
- Modern white LED through-the-dial lighting provides clear visibility during nighttime use
- 4 in 1 gauge design saves valuable real estate on your dash while allowing you to monitor critical parameters
- 12 and 16 volt compatible, well-suited with nearly every street car or race car electrical system
- AutoMeter’s race proven air-core electric instruments provide quick and accurate readings while keeping hazardous fluids outside of the vehicle
- Gauge kit includes 1/8” NPT pressure sender, 1/4” NPT adapter, 1/8” NPT temperature sender, 3/8” and 1/2" NPT adapters, mounting hardware, and detailed instructions for installation
Specifications
| Range | 100 PSI/100-250 °F/8-18V/240OE-33OF |
| Size - Standard - IN | 5" IN |
| Cross Sell | 9114, 3262, 3299, 5284, 9114, 3263 |
| Upsell | 9114, 3262, 3299, 5284, 9114, 3263 |
| Dial Color | Black |
| Includes Mounting Hardware | Bracket Included |
| Cup/Hole Size - Metric - MM | 117.5mm MM |
| Size - Metric - MM | 127mm MM |
| Related Item | 2160, BEX-3000, EP-800, 0423XL |
| Includes Adapter/Fitting | 3/8" NPT and 1/2" NPT adapter fittings |
| Outer Bezel Diameter | 4-15/16" IN |
| Cup/Hole Size - Standard - IN | 4-5/8" IN |
| Outer Bezel Diameter - Standard | 4-5/8" IN |
| Includes Sensor Unit | Oil Sender 2242 - Water Sender 2258 |
| Gauge Type | Quad Gauge |
| Bezel Style | Street Rod |
| Lighting Color | White |
| Bezel Color | Chrome |
| Series | DESIGNER BLACK II |
| Lens Style | Domed, Clear |
| Movement | Electric, Air-Core |
| Pointer Color | Fluorescent Red |
| Lighting Type | LED |
Short Description: GA 5" QD 240-33 DBII
Invoice Description: 5" QUAD GAUGE, LED, DESIGNER BLACK II
Definition: Electronic Multi-Purpose Gauge
Installation Guide: Download PDF
Installation / Product Video: Watch on YouTube
