AutoMeter 5646 - GAUGE, PYRO. (EGT), 2 1/16", 1600?F, STEPPER MOTOR W/PEAK & WARN, ELITE
Product Availability Request
Fill the form and our team will contact you.
2-1/16" PYROMETER, 0-1600 F, ELITE
Watching your precise exhaust temperature can mean the difference between maximum performance and catastrophic engine damage. On high output diesel or forced induction applications, there are few gauges that are more critical. AutoMeter’s Digital Stepper Motor display combined with our high definition LED backlighting make viewing your exact exhaust temperature effortless. The included Type K thermocouple assures maximum accuracy and minimum response time. There is, quite simply, not a better measurement of your exact exhaust gas temperature available anywhere, for any price. A variety of included installation options and direct plug in harness simplify installation on any application.
Features
- 7 user selectable colors (blue, white, red, green, cyan, violet, and yellow) to match visual preferences of driver and visibility conditions
- Built-in Pro-Control circuits with custom programmable activation & deactivation points for key functions like lights, fans, switches, & pumps allow drivers to focus on the competition while the gauges control key vehicle systems
- Set custom alert High and Low points specific to your vehicle & receive full dial warning notification to highlight the need for driver attention
- Acquire data for later review with one-touch Peak Recall functionality
- Gauge kit includes Type-K Thermocouple, wiring harness, thermocouple installation kit, mounting hardware, and detailed instructions for installation
- 12 and 16 volt compatible, compatible with nearly every street car or race car electrical system
- AutoMeter’s race proven digital stepper motor electric instruments provide unmatched accuracy which is further increased by utilizing a self calibration sequence during power up
Specifications
| Range | 0-1600 °F |
| Cup/Hole Size - Standard - IN | 2-1/16" IN |
| Outer Bezel Diameter - Standard | 2-1/16" IN |
| Size - Standard - IN | 2-1/16" IN |
| Outer Bezel Diameter | 2-1/4" IN |
| Related Item | 2163, BEX-5000, EP-800, 0424XL |
| Includes Mounting Hardware | 2230 |
| Includes Adapter/Fitting | 3256 |
| Cup/Hole Size - Metric - MM | 52.4mm MM |
| Size - Metric - MM | 52.4mm MM |
| Includes Sensor Unit | 5296 |
| Includes Wire Harness | 5296 |
| Lighting Color | 7 User Selectable Colors |
| Cross Sell | 9114, 5255, 2121, 2205, 5670, 5658 |
| Upsell | 9114, 5255, 2121, 2205, 5670, 5658 |
| Dial Color | Black |
| Bezel Color | Brushed Aluminum |
| Movement | Electric, Digital Stepper Motor |
| Series | ELITE |
| Lens Style | Flat, Clear |
| Pointer Color | Fluorescent Red |
| Lighting Type | LED |
| Gauge Type | Pyrometer |
| Bezel Style | Super Bezel |
Short Description: GA 2" EGT 1600F ELIT
Invoice Description: 2-1/16" E.G.T. PYRO, 0- 1600`F, ELITE
Definition: Pyrometer
Installation Guide: Download PDF
Installation / Product Video: Watch on YouTube
