BDS Suspension BDS1635FS - 2 Inch Leveling Kit Ram 2500 w/ Rear Air Ride 14-24 4WD W/ Fox 2.0 Performance Shocks

Level the front of your 2014-2024 RAM 2500 4WD air ride equipped truck by installing this 2-inch leveling kit from BDS. Designed to improve stance this kit includes everything necessary to set your truck up right with clearance for up to 35 inch Tires at an affordable price.

The lift kit includes steel fabricated coil spacers, extended bump stops, air ride sensor bracket, and custom-tuned NX2 Nitro or FOX 2.0 Performance series shocks.

• Front Lift Method: Coil Spacer
• Rear Lift Method: Stock
• Shocks Included: Yes
• Front Lift Height: 2 Inch
• Rear Lift Height: 0 Inch

1. Fits OE Equiped Air Ride systems only

• Easy, 100 percent Bolt-on installation
• Maintains factory like ride quality
• Standard NX2 Nitro shocks with vehicle-specific valving for better control
• Upgrade to FOX 2.0 Performance Series shocks for maximum performance on and off-road

FOX 2.0 Performance Series

• 2-inch Impact extruded aluminum body
• Internal floating piston (Internal Floating Piston) monotube design
• CNC machined 6061-T6 aluminum mounting ends
• Massive 5/8-inch hard chrome plated heat-treated alloy steel shaft
• Race-developed high-flow piston design
• Application-specific valving to maximize performance
• Long-lasting clear anodized finish

Tire Size: 35 x 12.5 Tire Size 2: 35 x 12.5 Wheel Diameter: 18 x 9 Wheel Diameter 2: 20 x 9 Back Spacing: 5/5

Kit Components:

• Includes one BDS012205, 2014-2024 Ram 2500 2 Inch w/rear AirRide, UPC Code 658848612086
• Includes two FOX98224709, Fox 2.0 Shock - 23.65 x 15.05 x 2- Special/EB1
• Includes two FOX98224710, Fox 2.0 Shock 23.27 x 14.65 x 2- S50/EB1

Warranty

Lifetime Replacement Warranty Extends to Cover all BDS Hard Parts

Specifications
