Bilstein 24-323680 - Suspension Shock Absorber B8 5100 (Ride Height Adjustable) Monotube 2021-2025 Ford F-150
Product Availability Request
Fill the form and our team will contact you.
46mm Monotube Shock Absorber
Bilstein B8 5100 (Ride Height Adjustable) shock absorbers are designed for trucks and SUVs with an OE coilover style suspension. Multiple snap-ring grooves in the body allow for different spring seat positions, providing 0-3 inches of front lift with OE springs (depending on application). The monotube shock absorbers feature a 46mm digressive piston a with self-adjusting deflective disc valve setting.Β Bilstein B8 5100 (Ride Height Adjustable) shock absorbers provide increased wheel travel and improved handling. Utilizing a B8 5100 (Ride Height Adjustable) shock absorber is the easiest way to level out your vehicle.
Features
- 46mm monotube design ensures consistent, fade-free performance in all conditions
- Practical alternative to coil spring spacers, with the benefit of Bilstein monotube technology
- Adjustable spring seat offers 0-2.75in of lift, depending on the application
Specifications
| Body Design | Snap Ring Grooved Body (Coilover) |
| Internal Design | Monotube |
| Adjustable Damping | Non-Adjustable |
| Collapsed Length (IN) | 16.85 |
| Finish | Zinc Plated |
| Series | B8 5100 (Ride Height Adjustable) |
| Upper Mount Type | Stem |
| Boot Included | No |
| Extended Length (MM) | 564.5 |
| Reservoir | No |
| Extended Length (IN) | 22.22 |
| Lower Mount Type | Crossbar |
| Spring Seat Included | No - Reuse OEM |
| Segment | Light Truck |
| PartType | Shocks / Struts |
| Prop 65 (Y/N) | Y |
| Piston Diameter | 46mm |
| Collapsed Length (MM) | 428.0 |
| Stroke/Travel Length (mm) | 136.4 |
| Shaft Diameter | 18mm |
| Stroke/Travel Length (IN) | 5.37 |
Short Description: Shock
Invoice Description: Ford F150 4WD; '21+; F; B8 5100; 0-2.5"
Definition: Suspension Shock Absorber
Installation Guide: Download PDF
Warranty: Limited Lifetime Warranty
| Year | Make | Model | Submodel |
|---|---|---|---|
| 2021-2025 | Ford | F-150 | King Ranch |
| 2021-2025 | Ford | F-150 | Lariat |
| 2021-2023 | Ford | F-150 | Limited |
| 2021-2025 | Ford | F-150 | Platinum |
| 2024-2025 | Ford | F-150 | STX |
| 2021-2025 | Ford | F-150 | Tremor |
| 2021-2025 | Ford | F-150 | XLT |
| 2021-2025 | Ford | F-150 | XL |
8 applications listed.
