Magnaflow xMOD Series Carbon Fiber Tips Cat-Back System
MagnaFlow XMOD Series Cat-Back Performance Exhaust System 19547 for the 2011-2021 Subaru WRX offers the premium features MagnaFlow products are known for: lifetime warrantied multi-metal construction, dyno-proven performance featuring straight-through mufflers and fast-flowing mandrel bent pipes. Specially engineered, interchangeable components equipped with race bred V-Band clamps allow you to easily switch from MagnaFlow’s aggressive exhaust note with the xMOD Muffler Module to the wild sounds offered by the xMOD xTreme Deletes. PLEASE NOTE: While xMOD systems are 100% emissions legal, the use of xTreme Deletes is recommended for track use only. Check local noise regulations for street legality. Unique to this system, the xMOD Series for the WRX is the very first to feature a dual resonator No Drone Technology (NDT) setup. Tuned to passively cancel out two of the different sound frequencies that can create low, exasperated drone, we are able to maintain the distinctive note of the Boxer motor while drastically improving the in-cabin experience regardless of the system’s configuration. xMOD for the Subaru WRX: get the sound you want, when you want it.
Features & Benefits
- xTreme Delete Modules for a straight-pipe setup
- No-Drone-Technology allows for a quiet cabin
- Configurable sound from mild to wild
Specifications
| Muffler (Rear Right) Body Length | 10 IN |
| Muffler (Rear Right) Body Width | 5 IN |
| Muffler (Rear Right) Type | Straight-Through |
| Muffler Body Height Position Center | 4 IN |
| Muffler Body Height Position Rear Left | 4 IN |
| Muffler Body Height Position Rear Right | 5 IN |
| Muffler Body Length Position Center | 14 IN |
| Muffler Body Length Position Front | 14 IN |
| Muffler Body Length Position Rear Left | 11 IN |
| Muffler Body Length Position Rear Right | 10 IN |
| Muffler Body Material | Stainless Steel |
| Muffler Body Width Position Center | 4 IN |
| Muffler Body Width Position Front | 4 IN |
| Muffler Body Width Position Rear Left | 4 IN |
| Muffler Body Width Position Rear Right | 5 IN |
| Muffler Finish | Polished |
| Muffler Quantity | 4 |
| Muffler Type | Straight-Through;Tuned Chamber |
| Muffler Type Position Center | Straight-Through |
| Muffler Type Position Front | Tuned Chamber |
| Muffler Type Position Rear Left | Tuned Chamber |
| Pipe Material | Stainless Steel |
| Series | xMOD |
| Title | MagnaFlow xMOD Series Cat-Back Performance Exhaust System 19547 |
| Type | Cat-Back |
| Valve Included | No |
| Clamps Included | Yes |
| Exhaust Tip Connection | Welded-On |
| Exhaust Tip Cut | Angle Cut |
| Exhaust Tip Diameter | 4.625 IN |
| Exhaust Tip Edge | Rolled Edge |
| Exhaust Tip Finish | Carbon Fiber |
| Exhaust Tip Intercooled | No |
| Exhaust Tip Length | 6 IN |
| Exhaust Tip Material | Carbon Fiber |
| Exhaust Tip Quantity | 1 |
| Exhaust Tip Resonated | No |
| Exhaust Tip Shape | Round |
| Exhaust Tip Wall | Double Wall |
| Exit Style | Single Straight Driver Side Rear |
| Gasket Or Seal Included | No |
| Hangers Included | Yes |
| Inlet Type | Bolt-On |
| Main Piping Diameter | 3 IN |
| Mounting Bracket Included | No |
| Muffler (Center) Body Height | 4 IN |
| Muffler (Center) Body Length | 14 IN |
| Muffler (Center) Body Width | 4 IN |
| Muffler (Center) Type | Straight-Through |
| Muffler (Front) Body Length | 14 IN |
| Muffler (Front) Body Width | 4 IN |
| Muffler (Front) Type | Tuned Chamber |
| Muffler (Rear Left) Body Height | 4 IN |
| Muffler (Rear Left) Body Length | 11 IN |
| Muffler (Rear Left) Body Width | 4 IN |
| Muffler (Rear Left) Type | Tuned Chamber |
| Muffler (Rear Right) Body Height | 5 IN |
| Catalytic Converter Included | No |
| Clamping Type | V Band |
Installation Guide: Download PDF
