MagnaFlow Exhaust Products 19625 - Overland Series Cat-Back System
Couldn't load pickup availability
Magnaflow Overland Series Black Cat-Back System
The MagnaFlow® Toyota Sequoia Overland Series™ Cat-Back Performance Exhaust System #19625 offers the improved off-road capabilities, higher ground clearance, dyno-proven performance and signature MagnaFlow® sound necessary to turn your 2023-2024 Toyota Sequoia into the ultimate overlanding vehicle. #19625’s direct-fit design is easy to install and replaces your SUV’s stock exhaust components from near the catalytic converter on back. This Toyota Sequoia exhaust system features 3” mandrel bent main piping that passes through a 22” oval bodied muffler and 11” round bodied muffler in addition to an NDT (No Drone Technology) reflection chamber before ending in a high clearance, tucked black-coated tailpipe to the rear of the driver’s side. The integration of MagnaFlow®’s NDT technology means that droning noises at highway cruising speeds are kept to a minimum. One of the system’s mufflers features an accessory port, where various included modules can be attached to further augment your rig’s engine sound. An additional NDT resonator module can be attached for further droning reduction in various frequency ranges, or the port can be covered with the included pipe cap for a more traditional MagnaFlow® exhaust sound. Together with the included J-pipe module, these attachments can be combined in various configurations to tune out a variety of different droning frequencies. The high clearance nature of the design and tucked exit of this system means both improved ground clearance and departure angles for superior off-road performance. This performance exhaust system is made of durable stainless steel backed by MagnaFlow®’s limited lifetime warranty.
Features & Benefits
- High clearance exit
- No-Drone-Technology allows for a quiet cabin
- Dyno proven performance
Specifications
| Exhaust Tip Quantity | 0 |
| Muffler (Front Left) Body Width | 11 IN |
| Muffler (Rear) Body Length | 11 IN |
| Muffler (Front Left) Body Length | 22 IN |
| Main Piping Diameter | 3 IN |
| Muffler (Front Right) Body Height | 4 IN |
| Muffler (Front Right) Body Width | 4 IN |
| Muffler (Front Left) Body Height | 5 IN |
| Muffler (Rear) Body Height | 5 IN |
| Muffler (Rear) Body Width | 5 IN |
| Muffler (Front Right) Body Length | 6 IN |
| Muffler (Rear) Finish | Black Coated |
| Inlet Type | Bolt-On |
| Muffler (Front) Finish | Brushed |
| Gasket Or Seal Included | No |
| Mounting Bracket Included | No |
| Exit Style | Single Straight Driver Side Rear |
| Muffler (Front Left) Type | Straight-Through |
| Muffler (Front Right) Type | Tuned Chamber |
| Clamps Included | Yes |
| Hangers Included | Yes |
| Muffler (Rear) Type | Straight-Through |
| Muffler Body Height Position Front Left | 5 IN |
| Muffler Body Height Position Front Right | 4 IN |
| Muffler Body Height Position Rear | 5 IN |
| Muffler Body Length Position Front Left | 22 IN |
| Muffler Body Length Position Front Right | 6 IN |
| Muffler Body Length Position Rear | 11 IN |
| Muffler Body Material | Stainless Steel |
| Muffler Body Width Position Front Left | 11 IN |
| Muffler Body Width Position Front Right | 4 IN |
| Muffler Body Width Position Rear | 5 IN |
| Muffler Finish Position Front | Brushed |
| Muffler Finish Position Rear | Black Coated |
| Muffler Quantity | 3 |
| Muffler Type | Straight-Through;Tuned Chamber |
| Muffler Type Position Front Left | Straight-Through |
| Muffler Type Position Front Right | Tuned Chamber |
| Muffler Type Position Rear | Straight-Through |
| Pipe Material | Stainless Steel |
| Series | Overland |
| Type | Cat-Back |
| Valve Included | No |
| Catalytic Converter Included | No |
| Clamping Type | Round Band |
| Title | MagnaFlow® 2023-2025 Toyota Sequoia 3.4L Overland Series™ Cat-Back Performance Exhaust System 19625 |
Installation Guide: Download PDF
