Centerforce 519026651 - (R) Diesel Twin and Flywheel Kit
Product Availability Request
Fill the form and our team will contact you.
This Centerforce Twin Disc clutch offers smooth engagement, quiet operation, light pedal, and high-end holding capacity.
Available for Dodge Cummins Diesel equipped 2500-5500 trucks. Centerforce announces their NEW Twin Disc clutch set for Heavy-Duty street and towing use. Truck owners pushing power levels up to 1700 ft/lbs will enjoy the smooth and quiet operation this unique clutch set offers. All components are match balanced and ready for installation.
Specifications
| Out of Package Weight | 109.10 |
| Disc Material | Organic/Carbon composite |
| Disc Type | Segmented face |
| Clutch Bolt Pattern | 22 |
| Ring Gear O.D. | 15.625 IN |
| Clutch Disc Diameter | 12.250 IN |
| Material | Billet Steel Flywheel / Cast Iron Pressure Plate / Segmented Organic Friction |
| Crankshaft Bolt Hole Quantity | 8 |
| Flywheel Crank Flange Register | 5.118 IN |
| Flywheel Counter Balance Weight | 0 |
| Flywheel Crank Bolt Size | M12 x 1.25 x 32 MM |
| Installed Height | 4.475 IN |
| Release Bearing Included | Yes |
| Release Bearing Style | Flat Face |
| Pilot Bushing Included | Yes |
| Pilot Bushing Material | Bearing |
| Alignment Tool Included | Yes |
| Mounting Hardware Included | Yes |
| Title | Centerforce ? Diesel Twin and Flywheel Kit, 109.10 lbs, 152 Tooth Gear, 0 in/oz Internally Balanced, 8 Bolt Crank, 1700 ft/lbs Capacity, 12.250in Dia., 10-Spline, Fits Dodge/Ram Cars and Trucks 5.9L/6.7L |
| Made In The USA | Assembled |
| Torque Capacity | 1700 |
| Tooth Quantity | 152 |
| California Proposition 65 | WARNING - Includes Nickel - cancer. www.P65Warnings.ca.gov. |
| Disc Type Sprung Solid | Sprung |
| Input Shaft Diameter | 1-3/8 IN |
| Counterweight Assist | YES |
| Input Spline Quantity | 10 |
Installation Guide: Download PDF
