Edelbrock 50459 E-Street Big-Block ChevyHead Cylinder Head Oval COMPLETE Single
Product Availability Request
Fill the form and our team will contact you.
The #50459 E-Street cylinder 290 Oval Port heads are designed for BBChevy applications. American made quality and affordable performance, These heads feature as-cast ports and are designed for entry-level application
The Edelbrock #50459 E-Street cylinder 290 Oval Port head is designed for Big-Block applications. The Edelbrock E-Street cylinder head offers American made quality and affordable performance. E-Street cylinder head features as-cast ports and are designed for entry-level street performance applications operating in the idle-to-5500 rpm range. The modern combustion chamber designs improve the combustion process and larger than stock intake and exhaust ports move more air through your engine for improve efficiency. For use on pre-pollution controlled vehicles only.
Specifications
| Push Rod Diameter | (Suggested) 0.4375 IN |
| Valve Stem Diameter | 0.3438 IN |
| Rocker Arm Stud Diameter | 0.4375 IN |
| Deck Thickness | 0.5625 IN |
| Valve Spring Maximum Lift | 0.700 IN |
| Valve Spring Diameter | 1.50 IN |
| Exhaust Valve Diameter | 1.88 IN |
| Combustion Chamber Volume | 110 CCM |
| Exhaust Runner Volume | 110 CCM |
| Intake Valve Diameter | 2.19 IN |
| Valve Angle | 26 DD |
| Intake Runner Volume | 290 CCM |
| Horsepower | 400-500 HJ |
| Head Casting Number | 6045F |
| Deck Height | 9.8 IN |
| Material | Aluminum |
| Valve Lock Material | Chromoly Steel |
| Guide Plate Material | Chromoly Steel |
| Construction Type | Complete |
| Seat Material | Ductile Iron |
| Family | E-Street |
| Series | E-Street |
| Seat Angle | Exhaust 45 deg/Intake 45 DD |
| Camshaft Type | Flat Tappet |
| Guide Plate Material | Hardened Steel |
| Guide Material | Manganese Bronze |
| Rocker Arms Included | No |
| Cylinder Head Gasket Included | No |
| Valve Cover Gasket Included | No |
| Mounting Hardware Included | No |
| EGR Port | No |
| Grade Type | Performance |
| Quantity | Sold Individually |
| Exhaust Port Location | Standard |
| Valve Lock Material | Steel |
| RGL | WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov. |
| Valve Spring Retainers Included | Yes |
| Valve Locks Included | Yes |
| Rocker Arm Studs/Bolts Included | Yes |
| Assembled | Yes |
| Guide Plates Included | Yes |
| Valve Springs Included | Yes |
| Valve Seals Included | Yes |
| Valves Included | Yes |
| CNC Ported | Yes |
| Retainer Included | Yes |
| Valve Included | Yes |
β οΈ California Proposition 65 Warning
California Residents: This product can expose you to chemicals which are known to the State of California to cause cancer or other reproductive harm. Please visit www.p65warnings.ca.gov for more information.
Warranty: 12 Months
