ICON Vehicle Dynamics K93204TA - 19-21 FORD RANGER 0-3.5" STAGE 4 SUSPENSION SYSTEM W TUBULAR UCA AL KNUCKLE
This part fits specific vehicles. Select your vehicle to check the fit. You can still add it to your cart.
Product Availability Request
Fill the form and our team will contact you.
Lifting the front suspension of trucks while improving ride quality and off-road capability, the ICON K93204TA Stage 4 suspension system uses 2.5 Series extended travel coilover shocks with remote reservoirs paired with ICON-engineered steel coil springs and tubular upper control arms. Fits the 2019-2021 Ford Ranger. The system features height-adjustable coilovers allowing 0-3.5 inches of front lift, providing a 35% increase in wheel travel over stock while accommodating larger tires such as the recommended 33" x 11.25" size. Included components comprise remote reservoir front shocks, 2.5 Aluminum Series piggyback rear shocks, tubular control arms with patented Delta Joint technology, and a foam bump stop kit, all featuring corrosion-resistant finishes and fully serviceable internals.
- System Type: Stage 4 (Tubular)
- Suspension Type: Passive
- Front Shock Design: 2.5 Series Extended Travel, Remote Reservoir
- Front Shock Body Diameter: 2.5 IN
- Rear Shock Design: 2.5 Aluminum Series Piggyback Reservoir
- Rear Shock Body Diameter: 2.5 IN
- Coil Spring Material: Steel
- Coil Spring Color: Black
- Coil Spring Rate: 650 PPI (Linear)
- Coil Spring Maximum Inside Diameter: 3 IN
- Coil Spring End Type: Square
- Coil Quantity Front: 2
- Upper Control Arms: Tubular with Patented Delta Joint Design
- Shock Finish: CAD Plated (Front), Hard Anodized (Rear)
- Shock Bearings: FK Rod End
- Bushings Included: Yes
- Mounting Hardware Included: Yes
- Bump Stop Kit: Foam, Included
- Lift Adjustment Range: 0-3.5"
- Front Wheel Travel Increase: 35% over Stock
- Recommended Tires: 33" x 11.25"
- Recommended Wheels: 17x8.5" w/ 5.75" Backspace / 25mm Offset
- Recommended Wheels: 18x9" w/ 6.00" Backspace / 25mm Offset
- OEM Wheel/Tire Fitment: Yes
- Installation: Direct Bolt-In
- Shocks: Fully Rebuildable and Revalvable
- Coils Quantity Front: 2
- Grade Type: Performance
- Add-On Part: 191003 - ICON SHORT 2.5 COIL WRAP W/LOGO PAIR (11.25-12.25)
- OEM Wheels & Tires Fitment: Yes
- Shocks Included: Yes
Weight: 104 lb
Country of Origin: United States
