Magnaflow xMOD Series Carbon Fiber Tips Cat-Back System
Configure your Dodge Challenger for the sound you want, when you want it! MagnaFlow's premium performance exhaust offering, the xMOD Series, provides an unrivaled exhaust experience! The revolutionary MagnaFlow Dodge Challenger XMOD Series Cat-Back Performance Exhaust System 19536 offers a completely modular exhaust system with all the benefits a MagnaFlow premium exhaust is known for: lifetime warrantied stainless-steel construction, dyno-proven performance featuring straight-through mufflers and fast-flowing mandrel bent pipes. xMOD’s core feature is the ability to configure your sound utilizing specifically engineered, interchangeable modules. Challenger xMOD Muffler Modules offer MagnaFlow's proven straight-through core design with 5” round by 14" long bodies, and now feature race bred v-band clamps for quick installation and removal. Easily switch from the deep, aggressive signature MagnaFlow exhaust note to the wild straight-pipe race car sound offered by the xMOD xTreme Deletes. xMOD xTreme Deletes for the Challenger come equipped with the same race bred v-band clamps which allow removal of the Muffler Modules for that xMOD xTreme sound experience. PLEASE NOTE: While xMOD systems are 100% emissions legal, the use of xTreme Deletes is recommended for track use only. Check local noise regulations for street legality. In addition to the xMOD variable sound and flow modules, this system incorporates MagnaFlow’s latest exhaust tuning advancement called No Drone Technology (NDT). MagnaFlow’s NDT, along with careful muffler design and placement, utilizes 1/4 wave passive noise cancellation to remove unwanted drone that can occur when creating a maximum performance, high flow exhaust system.
Features & Benefits
- xTreme Delete Modules for a straight-pipe setup
- No-Drone-Technology allows for a quiet cabin
- Configurable sound from mild to wild
Specifications
| Catalytic Converter Included | No |
| Muffler (Front) Body Length | 11 IN |
| Muffler (Rear) Body Length | 11 IN |
| Muffler Body Length Position Front | 11 IN |
| Muffler Body Length Position Rear | 11 IN |
| Main Piping Diameter | 3 IN |
| Muffler (Rear) Body Height | 4 IN |
| Muffler (Rear) Body Width | 4 IN |
| Exhaust Tip Quantity | 4 |
| Exhaust Tip Diameter | 4 IN |
| Muffler Quantity | 4 |
| Muffler Body Height Position Rear | 4 IN |
| Muffler Body Width Position Rear | 4 IN |
| Muffler (Center) Body Height | 5 IN |
| Muffler (Front) Body Width | 5 IN |
| Muffler Body Height Position Center | 5 IN |
| Muffler Body Width Position Front | 5 IN |
| Exhaust Tip Length | 6.75 IN |
| Valve Type | Actuated |
| Exhaust Tip Cut | Angle Cut |
| Exhaust Tip Finish | Carbon Fiber |
| Exhaust Tip Material | Carbon Fiber |
| Type | Cat-Back |
| Inlet Type | Clamp-On |
| Exhaust Tip Connection | Clamp-On |
| Exhaust Tip Wall | Double Wall |
| Title | MagnaFlow xMOD Series Cat-Back Performance Exhaust System 19536 |
| Gasket Or Seal Included | No |
| Exhaust Tip Resonated | No |
| Exhaust Tip Intercooled | No |
| Muffler Finish | Polished |
| Exit Style | Quad Split Rear |
| Exhaust Tip Edge | Rolled Edge |
| Exhaust Tip Shape | Round |
| Pipe Material | Stainless Steel |
| Muffler Body Material | Stainless Steel |
| Muffler (Front) Type | Straight-Through |
| Muffler Type Position Front | Straight-Through |
| Muffler Type | Straight-Through;Tuned Chamber |
| Muffler (Rear) Type | Tuned Chamber |
| Muffler Type Position Rear | Tuned Chamber |
| Series | xMod |
| Clamps Included | Yes |
| Hangers Included | Yes |
| Valve Included | Yes |
| Mounting Bracket Included | Yes |
| Clamping Type | Round Band |
| Clamping Type | V Band |
Installation Guide: Download PDF
