Oracle Lighting 5917-023 Integrated Windshield Roof LED Light Bar System for Wrangler JL / Gladiator JT

ORACLE Lighting Integrated Windshield Roof LED Light Bar System for Jeep Wrangler JL & Gladiator JT

If you are in the market for a high-mount LED Light bar and want to retain an almost factory look, the new ORACLE Integrated LED Light Bar is for you! While other offerings look obviously after-market or like an afterthought, our Patented Integrated design with its molded cowling integrates into the factory roof line of your Jeep. Along with blending in with the factory design, the unique cowl design also provides a quieter and more aerodynamic installation compared to traditional LED light bar setups. The polycarbonate housing is designed to match the styling of the factory hardtop. The light bar features reflector-facing LED technology so if it does not look like a traditional light bar that's because it's not. This reflector system is designed to provide optimized LED light output from the 30 individual 8W LED emitters creating at total of 18,000 raw lumens and a projection distance of over 600 meters. As an added bonus, the system features selectable Amber or White clearance lights. You can select to connect these lights to an Aux Switch, Parking Lights, DRL, or just leave them disconnected if you prefer not to have the clearance light feature on your Jeep.

Features

• Innovative Patent-Pending Design
• Designed and Engineered in the USA
• LED Lifespan 50,000+ Hours/ 1 Year Warranty
• Raw Lumen Light Output: 18,000LM
• Effective Lumen Light Output: 14,200LM
• Peak Intensity: 420,000CD
• Total Wattage: 240 Watts
• Total Amp Draw: 14A @12V DC
• Beam Angle: 40° Driving Beam
• Max Projection Distance: 1Lux@648M
• Color Temperature: 5500K
• Aerodynamic Integrated Housing Design
• Outer Housing Material: Polycarbonate
• Lamp Housing Material: 6030 Aluminum
• Reflector Material: Plated Polycarbonate
• Lens: Material: Lexan Polycarbonate
• Lamp Finish: Polyester Powder Coat
• Stainless Steel Anti-Fog Breather Valves
• Molded IP68 Waterproof Connectors
• Waterproof Rating: IP68 Ingress Protection
• High-Powered Lighting 30x 8W LED Main Light
• Selectable Amber or White Clearance Lights
• Precision LED Reflector-Facing Technology
• Tool Included for Installation of Threaded Inserts
• Under/Over Voltage and Reverse Polarity Protection
• Electronic Thermal Management
• Innovative and Integrated Patented Design

Specifications

Note: As with any Roof Mounted Light-Bar setup, automatic Car-Washes with overhead brushes should be avoided. Part is only compatible with models with Hard-Top. Part will not fit models with Soft Top or One Touch Roof The light bar ships in a matte black color (to match unpainted hard tops) if you have a painted hard top the light bar housing can also be painted to match. We recommend using a professional painter to properly prep, prime, and color-match paint the housing.

⚠️ California Proposition 65 Warning
California Residents: This product can expose you to chemicals which are known to the State of California to cause cancer or other reproductive harm. Please visit www.p65warnings.ca.gov for more information.

Warranty: 1 Year
