Bilstein 33-314747 - Suspension Shock Absorber XVA Series Monotube
Product Availability Request
Fill the form and our team will contact you.
46mm Monotube Shock Absorber
Bilstein XVA Series shock absorbers features aluminum threaded body construction designed for motorsports applications. The large volume dual zone nitrogen bulb, with optional base valve (sold separately), allows for lower gas pressure for increased grip. These shock absorbers are available in non-, single and double adjustable configurations for precise on-vehicle tuning options. Pistons, piston bands and heims are sold separately to allow the greatest flexibility in upgrade combinations. XVA Series shock absorbers are ideal for racers looking for an aluminum, rebuildable design with multiple upgrade options and superior performance.
Features & Benefits
- 46mm extruded aluminum threaded body improves durability and heat dissipation
- Dual-zone gas bulb decreases gas pressure while increasing grip levels
- Optimized floating piston improves driver feel and response
Specifications
| Adjustable Damping | Single Adjustable - Rebound |
| Boot Included | No |
| Finish | Clear Anodized |
| Extended Length (IN) | 21.89 |
| Body Material | Aluminum |
| Series | XVA Series |
| Piston Type | Sold Separately |
| Internal Design | Monotube |
| Title | Bilstein Shock Absorbers |
| Extended Length (MM) | 556.0 |
| Body Design | Threaded Body Large Bulb Screw Top (Coilover) |
| Spring Seat Included | No |
| Segment | Motorsports |
| PartType | Shocks / Struts |
| Lower Mount Type | 1/2in Heim |
| Upper Mount Type | 1/2in Heim |
| Collapsed Length (IN) | 14.80 |
| Piston Diameter | 46mm |
| Collapsed Length (MM) | 376.0 |
| Shaft Diameter | 14mm |
| Stroke/Travel Length (mm) | 180.1 |
| Stroke/Travel Length (IN) | 7.09 |
⚠ WARNING: WARNING: Cancer & Reproductive Harm - www.P65Warnings.ca.gov
Installation Guide: Download PDF
