Magnaflow xMOD Series Black Chrome Cat-Back System
The MagnaFlow xMOD Series Cat-Back Performance Exhaust System with black chrome finish #19545 for the 2020-2025 Chevrolet Corvette C8 offers the modularity of MagnaFlow’s xMOD series in a compact package designed for high performance and durability. It took days of dyno and track testing to ensure that this exhaust kit does all this while enhancing the exhaust sound with our deep signature tone. MagnaFlow #19545 boosts the max power of your C8 by up to 18 hp and 17 lb. ft. of torque, with peak power gains of up to 12 hp and 13 lb. ft. of torque.†
Features & Benefits
- No-Drone-Technology allows for a quiet cabin
- xTreme Delete Modules for a straight-pipe setup
- Configurable sound from mild to wild
Specifications
| Exhaust Tip Quantity | 2 |
| Exhaust Tip Diameter | 4.5 IN |
| Exhaust Tip Length | 5.75 IN |
| Exhaust Tip Cut | Angle Cut |
| Exhaust Tip Finish | Black Chrome |
| Exhaust Tip Edge | Folded Edge |
| Exhaust Tip Intercooled | No |
| Exhaust Tip Material | Stainless Steel |
| Exhaust Tip Connection | Welded-On |
| Clamps Included | Yes |
| Exhaust Tip Resonated | No |
| Exhaust Tip Shape | Round |
| Exhaust Tip Wall | Double Wall |
| Exit Style | Quad Split Rear |
| Gasket Or Seal Included | Yes |
| Hangers Included | Yes |
| Inlet Type | Bolt-On |
| Main Piping Diameter | 3 IN |
| Mounting Bracket Included | No |
| Muffler Body Height | 5 IN |
| Muffler Body Length | 8 IN |
| Muffler Body Material | Stainless Steel |
| Muffler Body Width | 8 IN |
| Muffler Finish | Polished |
| Muffler Quantity | 2 |
| Muffler Type | Straight-Through |
| Pipe Material | Stainless Steel |
| Series | xMOD |
| Type | Cat-Back |
| Valve Included | Yes |
| Valve Type | Actuated |
| Catalytic Converter Included | No |
| Title | MagnaFlow 2020-2025 Chevrolet Corvette 6.2L xMOD Series Cat-Back Performance Exhaust System 19545 |
| Clamping Type | V Band |
Installation Guide: Download PDF
Specifications
MagnaFlow 19545 — Exhaust System Kit, fits 2020-2026 Chevrolet Corvette. Key specs: 3 in. main piping diameter, xmod series.
Warranty: Limited Lifetime Warranty from MagnaFlow
Also known as: UPC 00888563159713
Shipping Information
Free shipping is available for eligible orders.
Shipping: For USA - Up to 50lbs.
Orders are processed during normal business days. Delivery dates may vary by carrier and destination.
