MagnaFlow Exhaust Products 19683 - SPEQ Series Polished Cat-Back System
Couldn't load pickup availability
Magnaflow SPEQ Series Stainless Cat-Back System
The MagnaFlow 2025 RAM 1500 V6-3.6L SPEQ Series Cat-Back Performance Exhaust System 19683 brings out the personality of your Truck with our signature resonant, powerful exhaust tone and dyno-proven performance. #19683 3” diameter mandrel bent main piping passes through a specifically tuned performance oval muffler before exiting in a single passenger side rear exit with a 4” polished tip. This full-size truck exhaust kit is the perfect equalizer between sound and performance. Upgrade your truck to the next level with an exhaust that has the pipes to put other trucks to shame. With this system your truck will be producing moderate exterior and mild interior sound levels while leaving other trucks feeling envious at every stoplight. Exhaust kit 19683 features a cat-back exhaust layout that replaces your trucks stock exhaust components from near the catalytic converter on back. Extensive 3D scanning during development has resulted in a direct-fit design that you can easily install yourself. 19683 is produced using CNC precision robotic manufacturing techniques and is backed by MagnaFlow's 1-year limited finish warranty and limited lifetime construction warranty.
Features & Benefits
- Increased Horsepower and Torque
- 100% Stainless Steel
- No-Drone-Technology allows for a quiet cabin
Specifications
| Exhaust Tip Connection | Welded-On |
| Exhaust Tip Cut | Angle Cut |
| Exhaust Tip Diameter | 4 IN |
| Exhaust Tip Edge | Folded Edge |
| Exhaust Tip Intercooled | No |
| Exhaust Tip Length | 12 IN |
| Exhaust Tip Material | Stainless Steel |
| Exhaust Tip Quantity | 1 |
| Exhaust Tip Resonated | No |
| Exhaust Tip Shape | Round |
| Exhaust Tip Wall | Double Wall |
| Exit Style | Single Passenger Side Rear |
| Gasket Or Seal Included | Yes |
| Hangers Included | Yes |
| Inlet Type | Bolt-On |
| Main Piping Diameter | 3 IN |
| Mounting Bracket Included | No |
| Muffler Body Height | 5 IN |
| Muffler Body Length | 22 IN |
| Muffler Body Material | Stainless Steel |
| Muffler Body Width | 11 IN |
| Muffler Finish | Brushed |
| Muffler Quantity | 1 |
| Muffler Type | Straight-Through |
| Pipe Material | Stainless Steel |
| Series | SPEQ |
| Type | Cat-Back |
| Valve Included | No |
| Exhaust Tip Finish | Polished |
| Catalytic Converter Included | No |
| Title | MagnaFlow 2025 Ram 1500 3.6L SPEQ Series Cat-Back Performance Exhaust System 19683 |
| Clamping Type | Round Band |
Installation Guide: Download PDF
