MagnaFlow PRO DPF Series Diesel 5 in Filter-Back
The MagnaFlow PRO DPF Series 19694 utilizes it's weight-optimized, durable, corrosion resistant stainless steel design to enhance your truck with MagnaFlow’s signature sound and dyno-tested performance. 19694’s 5in. diameter mandrel bent main piping features a muffler delete and terminates in a Single Passenger Side Rear exit with 6in. Polished Welded-Single Wall-Angle Cut-Rolled Edge-Intercooled tips. This emissions-legal filter-back exhaust kit has been tuned to create Mild interior and Moderate exterior sound levels. Exhaust system 19694 is emissions-legal and produced using CNC precision robotic manufacturing techniques that result in a direct-fit design that you can install yourself, all backed by MagnaFlow’s limited lifetime warranty.
Features
- Intercooled tips
- Attention grabbing design thanks to an aggressive style
- Throaty, powerful performance sound Magnaflow is famous for
Specifications
| Clamps Included | Yes |
| Exhaust Tip Connection | Welded-On |
| Exhaust Tip Cut | Angle Cut |
| Exhaust Tip Diameter | 6 IN |
| Exhaust Tip Edge | Rolled Edge |
| Exhaust Tip Finish | Polished |
| Exhaust Tip Intercooled | Yes |
| Exhaust Tip Length | 13 IN |
| Exhaust Tip Material | Stainless Steel |
| Exhaust Tip Quantity | 1 |
| Exhaust Tip Resonated | No |
| Exhaust Tip Shape | Round |
| Exhaust Tip Wall | Single Wall |
| Exit Style | Single Passenger Side Rear |
| Gasket Or Seal Included | No |
| Hangers Included | Yes |
| Inlet Type | Clamp-On |
| Main Piping Diameter | 5 IN |
| Mounting Bracket Included | No |
| Muffler Quantity | 0 |
| Pipe Material | Stainless Steel |
| Prop 65 Y/N | No |
| Valve Included | No |
| Type | DPF Back |
| Catalytic Converter Included | No |
| Series | Pro DPF |
| Clamping Type | Round Band |
Note: Need further assistance? Call 1-800-990-0905.
Short Description: Filter-Back
Invoice Description: Exhaust System
Definition: Exhaust System Kit
Installation Guide: Download PDF
Specifications
MagnaFlow 19694 — Exhaust System Kit, fits 2007-2017 Chevrolet Silverado 2500 HD + 3 more. Key specs: 5 in. main piping diameter, pro dpf series.
Warranty: Limited Lifetime Warranty from MagnaFlow
Also known as: UPC 888563205021
| Year | Make | Model | Submodel | Engine |
|---|---|---|---|---|
| 2024-2026 | Chevrolet | Silverado 2500 HD | Custom | 6.6L V8 |
| 2024-2026 | Chevrolet | Silverado 2500 HD | High Country | 6.6L V8 |
| 2024-2026 | Chevrolet | Silverado 2500 HD | LTZ | 6.6L V8 |
| 2024-2026 | Chevrolet | Silverado 2500 HD | LT | 6.6L V8 |
| 2024-2026 | Chevrolet | Silverado 2500 HD | WT | 6.6L V8 |
| 2007-2023 | Chevrolet | Silverado 2500 HD | 6.6L V8 | |
| 2007-2026 | Chevrolet | Silverado 3500 HD | 6.6L V8 | |
| 2024-2026 | GMC | Sierra 2500 HD | AT4 | 6.6L V8 |
| 2024-2026 | GMC | Sierra 2500 HD | Denali | 6.6L V8 |
| 2024-2026 | GMC | Sierra 2500 HD | Pro | 6.6L V8 |
| 2024-2026 | GMC | Sierra 2500 HD | SLE | 6.6L V8 |
| 2024-2026 | GMC | Sierra 2500 HD | SLT | 6.6L V8 |
| 2007-2023 | GMC | Sierra 2500 HD | 6.6L V8 | |
| 2007-2026 | GMC | Sierra 3500 HD | 6.6L V8 |
14 applications listed.
