Bilstein 25-331790 - Suspension Shock Absorber B8 5165 Monotube
This part fits specific vehicles. Select your vehicle to check the fit. You can still add it to your cart.
Product Availability Request
Fill the form and our team will contact you.
A 46mm monotube shock absorber with remote reservoir, the Bilstein B8 5165 model 25-331790 features self-adjusting deflective disc valving that responds to surface changes for vehicle control. The remote reservoir increases shock oil capacity for heat dissipation. A 360 degree swivel banjo hose fitting provides low-profile installation, and both upper and lower mounts accept 5/8 inch eyelets with hour glass bushings. The boot is not included. The spring seat is not included.
- Piston diameter: 46mm
- Shaft diameter: 14mm
- Internal design: Monotube
- Mount type: Eye-to-Eye
- Upper mount: Eye 5/8in
- Lower mount: Eye 5/8in
- Reservoir: Yes
- Extended length: 24.42 inches (620.2mm)
- Collapsed length: 14.61 inches (371.0mm)
- Stroke/Travel length: 9.81 inches (249.2mm)
- Rebound @0.52m/s: 2495
- Compression @0.52m/s: 620
- Finish: Zinc plated
- Body design: Smooth body (non-coilover)
- Damping: Non-adjustable
- Boot included: No
- Spring seat included: No
- Optional reservoir clamp: 11-176015
Weight: 6.98 lb
Country of Origin: United States
