COMP Cams 54-478-11 2010-2019 GMC Sierra 2500 HD Engine Camshaft
COMP Cams 54-478-11 2010-2019 GMC Sierra 2500 HD Engine Camshaft
COMP Cams 54-478-11 2010-2019 GMC Sierra 2500 HD Engine Camshaft
COMP Cams 54-478-11 2010-2019 GMC Sierra 2500 HD Engine Camshaft
COMP Cams 54-478-11 2010-2019 GMC Sierra 2500 HD Engine Camshaft
COMP Cams
SKU 54-478-11

COMP Cams 54-478-11 LSR Centrifugal Blower 235/251 Hydraulic Roller Cam for GM LS GEN III/IV

$404.95 USD
Not legal for sale or use in California

This part has no CARB Executive Order, so it is not legal for sale or use on emissions controlled vehicles in California. Some other states follow California rules for many vehicles. Please check your state's rules before ordering.

Check Availability
Check availability, to reach.
Free US shipping on orders over $80
Warranty 12 Months

Working alongside a centrifugal blower, the COMP Cams 54-478-11 is a billet steel hydraulic roller camshaft from the LSR Centrifugal Blower series. Fits 192 Buick, Cadillac, Chevrolet, GMC and other vehicles from 1999 to 2019, including the 2003-2005 and 2010-2019 Chevrolet Express 2500 Base and Express 2500 LS and GMC Savana 2500 Base and the 2010-2019 Chevrolet Express 2500 LT, Express 3500 Base, Express 3500 LS, Express 3500 LT, Silverado 2500 HD LT, Silverado 2500 HD LTZ, Silverado 2500 HD WT, Silverado 3500 HD LT, Silverado 3500 HD LTZ and Silverado 3500 HD WT and GMC Savana 2500 LS, Savana 2500 LT, Savana 3500 Base, Savana 3500 LS, Savana 3500 LT, Sierra 2500 HD SLE, Sierra 2500 HD SLT, Sierra 3500 HD SLE and Sierra 3500 HD SLT. Full vehicle list below. The cam is listed for high RPM power when used with a centrifugal blower, with a basic operating RPM range of 2,500 to 7,200 RPM. The lobe separation is 115 deg, the intake valve lift is 0.621 in, and the exhaust valve lift is 0.624 in. Intake duration at .050 inch lift is 235 deg and exhaust duration at .050 inch lift is 251 deg, while the advertised durations are 285 deg intake and 301 deg exhaust. The lifters are not included, the assembly lubricant is not included, and valve springs are required, while the camshaft gear uses a 3-bolt attachment. The grind number is 285LCB HR15, the camshaft is used in 8 cylinder engines, and the warranty is 12 Months.

  • Camshaft Series: LSR Centrifugal Blower
  • Lobe Separation: 115 deg
  • Intake Valve Lift: 0.621 IN
  • Exhaust Valve Lift: 0.624 IN
  • Lifters Included: No
  • Valve Springs Required: Yes
  • Assembly Lubricant Included: No
  • Camshaft Gear Attachment: 3-Bolt
  • Camshaft Material: Billet Steel
  • Lifter Type: Hydraulic Roller
  • Cam Type: Hydraulic Roller
  • Grind Number: 285LCB HR15
  • Basic Operating RPM Range: 2,500-7,200 RPM
  • Intake Duration at .050 Inch Lift: 235 deg
  • Exhaust Duration at .050 inch Lift: 251 deg
  • Advertised Intake Duration: 285 deg
  • Advertised Exhaust Duration: 301 deg
  • C.A.R.B. Exempt for Racing and Off-Road Only Vehicles?: Yes, but must be a race/competition only vehicle.
  • C.A.R.B. Exempt for California Certified Vehicles Manufactured Before 1965?: Yes, but must meet tailpipe emission standards for year of vehicle.
  • C.A.R.B. Exempt for Federally Certified Vehicles Manufactured Before 1967?: Yes, but must meet tailpipe emission standards for year of vehicle.
  • C.A.R.B. Exempt for Foreign Vehicles Manufactured Before 1967?: Yes, but must meet tailpipe emission standards for year of vehicle.

Weight: 9.85 lb

Country of Origin: United States

California Residents: This product can expose you to chemicals which are known to the State of California to cause cancer or other reproductive harm. Please visit www.p65warnings.ca.gov for more information.

Vehicle Fitment Fits 262 vehicle applications (1999-2019).
