COMP Cams 01-418-8 Xtreme Energy 230/236 Hydraulic Roller Cam for Chevrolet Big Block GEN VI

Working with 2500+ stall converters and upgraded fuel systems, the Xtreme Energy hydraulic roller cam from COMP Cams (part number 01-418-8) delivers 0.51 inch valve lift for Chevrolet GEN VI 454 and 502 cubic inch 8-cylinder engines. Fits the 1996-2000 Chevrolet C2500, C3500, Express 3500, K2500 and K3500 and GMC C2500, C3500, K2500, K3500 and Savana 3500, the 1996-1999 Chevrolet C2500 Suburban, K2500 Suburban and P30 and GMC C2500 Suburban, K2500 Suburban and P3500, and the 1996 Chevrolet G30 and GMC G3500 with the 7.4L V8. This Austempered Ductile Iron cam operates from 2,200 to 5,800 RPM with 230 DD intake and 230 DD exhaust duration at.050 inch lift.

• Camshaft Series: Xtreme Energy
• Cam Type: Hydraulic Roller
• Grind Number: XR282HR
• Camshaft Material: Austempered Ductile Iron
• Intake Valve Lift: 0.51 IN
• Exhaust Valve Lift: 0.51 IN
• Advertised Intake Duration: 282 deg
• Advertised Exhaust Duration: 288 deg
• Intake Duration at.050 Inch Lift: 230 deg
• Exhaust Duration at.050 inch Lift: 230 deg
• Lobe Separation: 110 deg
• Basic Operating RPM Range: 2,200-5,800 RPM
• Usage: Street/Performance
• Lifter Type: Hydraulic Roller
• Camshaft Gear Attachment: 3-Bolt
• Lifters Included: No
• Valve Springs Required: Yes
• Assembly Lubricant Included: No
• Cam and Lifter Kit Upgrade: CL01-418-8
• K-Kit Upgrade: K01-418-8
• SK-Kit Upgrade: SK01-418-8
• C.A.R.B. Exempt for Racing and Off-Road Only Vehicles?: Yes, but must be a race/competition only vehicle.
