COMP Cams 26055-16 Engine Valve Spring Kit

Is this converter legal for your car? CARB legality checker · instant

Enter your Engine Family Number and we will confirm whether this exact converter is street-legal for your vehicle.

COMP Cams

SKU 26055-16

COMP Cams 26055-16 Race Sportsman 1.585" OD Beehive Springs, 1.925" Installed Height, 16 Springs

Name: COMP Cams 26055-16 Race Sportsman 1.585" OD Beehive Springs, 1.925" Installed Height, 16 Springs
Brand: COMP Cams
SKU: 26055-16
Price: 343.99 USD
Availability: InStock

$343.99 USD

In Stock · Fast Shipping

Free US shipping on orders over $80

Warranty 12 Months

Is this converter legal for your car? CARB legality checker · instant

Enter your Engine Family Number and we will confirm whether this exact converter is street-legal for your vehicle.

Beehive Valve Springs: Top 1.204" OD, .731" ID Bottom 1.585" OD, 1.112" ID

With a .640" maximum lift, these Beehive Valve Springs were designed for high end Solid flat tappet and hydraulic Roller cams. They have great for high performance street and oval track capabilities, and are also good for endurance Applications.

Specifications

Outer Bottom Spring Outside Diameter	1.585 IN
Outer Top Spring Inside Diameter	0.721 IN
Number of Springs	1
Outer Bottom Spring Inside Diameter	1.102 IN
Outer Top Spring Outside Diameter	1.204 IN
Coil Bind Height	1.225 IN
Seat Height	1.925 IN
Seat Pressure	150 PSI
Spring Rate	400 PPI
Compatible .570" Guide Diameter Spring Seats	4640-16
Compatible .630" Guide Diameter Spring Seats	4697-16
Compatible Spring Cup (O.D. Locator)	4702-16
Compatible Shims	4757
Compatible Retainer	785-16
Damper	No
Valve Spring Series	Race Sportsman

⚠️ California Proposition 65 Warning
California Residents: This product can expose you to chemicals which are known to the State of California to cause cancer or other reproductive harm. Please visit www.p65warnings.ca.gov for more information.

Warranty: 12 Months

Sold by Specification. This is an engine build part, chosen by its measurements rather than by year, make and model. Match the specifications to your build. If you are unsure, check with your mechanic or dealership. Making sure it fits is the customer's responsibility.

A vehicle fitment list isn’t available for this part.

Please check the product description for the manufacturer’s application details, or ask a specialist — we’ll confirm whether it fits your vehicle before you buy.
