COMP Cams 26125-16 Engine Valve Spring Kit

Is this converter legal for your car? CARB legality checker · instant

Enter your Engine Family Number and we will confirm whether this exact converter is street-legal for your vehicle.

COMP Cams

SKU 26125-16

COMP Cams 26125-16 Race Street 1.101" OD Beehive Springs, 1.640" Installed Height, 16 Springs

Name: COMP Cams 26125-16 Race Street 1.101" OD Beehive Springs, 1.640" Installed Height, 16 Springs
Brand: COMP Cams
SKU: 26125-16
Price: 331.99 USD
Availability: InStock

$331.99 USD

In Stock - Fast Shipping

Free shipping over $80 To the USA

Warranty 12 Months

Is this converter legal for your car? CARB legality checker · instant

Enter your Engine Family Number and we will confirm whether this exact converter is street-legal for your vehicle.

Beehive Valve Springs: Top 1.013" OD, .650" ID Bottom 1.101" OD, .738" ID

With a .650" maximum lift, these Beehive Valve Springs were designed for Ford 4.6L and 5.4L Modular 2 and 3 Valve engines and Duramax Applications.

Specifications

Valve Spring Series	Race/Street
Coil Bind Height	0.97 IN
Compatible Retainer	763-16
Damper	No
Number of Springs	1
Outer Bottom Spring Inside Diameter	0.738 IN
Outer Bottom Spring Outside Diameter	1.101 IN
Outer Top Spring Inside Diameter	0.65 IN
Outer Top Spring Outside Diameter	1.013 IN
Seat Height	1.64 IN
Seat Pressure	120 PS
Spring Rate	258

⚠️ California Proposition 65 Warning
California Residents: This product can expose you to chemicals which are known to the State of California to cause cancer or other reproductive harm. Please visit www.p65warnings.ca.gov for more information.

Warranty: 12 Months

Sold by Specification. This is an engine build part, chosen by its measurements rather than by year, make and model. Match the specifications to your build. If you are unsure, check with your mechanic or dealership. Making sure it fits is the customer's responsibility.

A vehicle fitment list isn’t available for this part.

Please check the product description for the manufacturer’s application details, or ask a specialist — we’ll confirm whether it fits your vehicle before you buy.
