COMP Cams 7228-16 Engine Valve Spring Kit

Is this converter legal for your car? CARB legality checker · instant

Enter your Engine Family Number and we will confirm whether this exact converter is street-legal for your vehicle.

COMP Cams

SKU 7228-16

COMP Cams 7228-16 Race Street 1.290" OD Conical Springs, 1.800" Installed Height, 16 Springs

Name: COMP Cams 7228-16 Race Street 1.290" OD Conical Springs, 1.800" Installed Height, 16 Springs
Brand: COMP Cams
SKU: 7228-16
Price: 378.99 USD
Availability: InStock

$378.99 USD

Check Availability

Check availability, to reach.

Free US shipping on orders over $80

Warranty 12 Months

Is this converter legal for your car? CARB legality checker · instant

Enter your Engine Family Number and we will confirm whether this exact converter is street-legal for your vehicle.

Conical Valve Springs 136 @ 1.800" / 412 @ 1.170"

Revolutionary Advancement In High Performance Spring Technology.

7228-16	Outer Diameter and	Inner Diameter and	Seat Load	Open Load	Coil Bind	Rate and
Top	1.020"	.650"	136 @ 1.800"	412 @ 1.170"	1.125"	438
Bottom	1.290"	.920"	136 @ 1.800"	412 @ 1.170"	1.125"	438

Specifications

Outer Top Spring Inside Diameter	0.662 IN
Outer Bottom Spring Inside Diameter	0.918 IN
Number of Springs	1
Outer Top Spring Outside Diameter	1.03 IN
Coil Bind Height	1.125 IN
Outer Bottom Spring Outside Diameter	1.286 IN
Seat Height	1.8 IN
Seat Pressure	136 PSI
Spring Rate	440 PPI
Compatible .570" Guide Diameter Spring Seats	4677-16
Compatible Shims	4753
Compatible Retainer	788-16
Damper	No
Valve Spring Series	Race/Street

⚠️ California Proposition 65 Warning
California Residents: This product can expose you to chemicals which are known to the State of California to cause cancer or other reproductive harm. Please visit www.p65warnings.ca.gov for more information.

Warranty: 12 Months

Sold by Specification. This is an engine build part, chosen by its measurements rather than by year, make and model. Match the specifications to your build. If you are unsure, check with your mechanic or dealership. Making sure it fits is the customer's responsibility.

A vehicle fitment list isn’t available for this part.

Please check the product description for the manufacturer’s application details, or ask a specialist — we’ll confirm whether it fits your vehicle before you buy.
