COMP Cams 7230-16 Engine Valve Spring Kit

Is this converter legal for your car? CARB legality checker · instant

Enter your Engine Family Number and we will confirm whether this exact converter is street-legal for your vehicle.

COMP Cams

SKU 7230-16

COMP Cams 7230-16 Race Sportsman 1.332" OD Conical Springs, 1.900" Installed Height, 16 Springs

Name: COMP Cams 7230-16 Race Sportsman 1.332" OD Conical Springs, 1.900" Installed Height, 16 Springs
Brand: COMP Cams
SKU: 7230-16
Price: 410.95 USD
Availability: InStock

$410.95 USD

In Stock · Fast Shipping

Free US shipping on orders over $80

Warranty 12 Months

Is this converter legal for your car? CARB legality checker · instant

Enter your Engine Family Number and we will confirm whether this exact converter is street-legal for your vehicle.

Conical Valve Springs 145 @ 1.900" / 495 @ 1.225"

Revolutionary Advancement In High Performance Spring Technology.

7230-16	Outer Diameter and	Inner Diameter and	Seat Load	Open Load	Coil Bind	Rate and
Top	1.060"	.660"	145 @ 1.900"	495 @ 1.225"	1.185"	520
Bottom	1.332"	.932"	145 @ 1.900"	495 @ 1.225"	1.185"	520

Specifications

Outer Top Spring Inside Diameter	0.66 IN
Compatible .570" Guide Diameter Spring Seats	4677-16
Compatible Shims	4754
Spring Rate	519 PPI
Compatible Retainer	788-16
Damper	No
Valve Spring Series	Race Sportsman
Outer Bottom Spring Inside Diameter	0.932 IN
Number of Springs	1
Outer Top Spring Outside Diameter	1.06 IN
Coil Bind Height	1.175 IN
Outer Bottom Spring Outside Diameter	1.332 IN
Seat Height	1.9 IN
Seat Pressure	145 PSI

Note: Available individually under 7230-1
